Pan Depth: 7-1/4”
Pan Capacity: 9 Quarts (9.5 Liters)
System Capacity: 10 Quarts (10.4 Liters)
Stroke Clearance: 4.125" (With Steel Rods, Check Crank Scraper Before Final Install)

Description: Billet ends and rails. It bolts through tubes on the right side and has circle track gating (7 trap doors), removable Louvered Windage tray, Oil level plug. The 1101A uses the reverse mount starter only. This is Similar to the Kevko 1097 Oil Pan, however it features a full Power Pouch. The Power Pouch will require low profile lower motor mount bolts to clear pouch.

UPDATE: As of March 1st 2023, we have converted our aluminum oil pans to install WITH gaskets. We recommend using the One Piece Fel-Pro Gaskets Listed below.

Oil Pump/Pickup Tube Reference
Pump	Pickup Diameter	Kevko Pickup Tube
M55, M55A, 10553ST	5/8	1003	ADD
M155, 10554ST	3/4	1003-3/4	ADD
M55HV, 10550ST	5/8	1005	ADD
M155HV, 10551ST	¾	1005-3/4	ADD
10555, 10552ST	¾ Bolt On	1005-10555	ADD
M99HVS	3/4	1010	ADD

Related Products

Pumps

M55	Standard Volume, Standard Pressure, 5/8"	ADD
M55A	Standard Volume, High Pressure, 5/8"	ADD
M155	Standard Volume, Standard Pressure, 3/4"	ADD
M55HV	High Volume, Standard Pressure, 5/8"	ADD
M155HV	High Volume, Standard Pressure, 3/4"	ADD
10550ST	Performance-25% Increased Volume, High Pressure, Shark Tooth, 5/8"	ADD
10551ST	Performance-High Volume, High Pressure, Shark Tooth, 3/4"	ADD
10552ST	Performance-10% Increased Volume, High Pressure, Shark Tooth, 3/4"	ADD
10553ST	Performance-Stock Volume, High Pressure, Shark Tooth, 5/8"	ADD
10554ST	Performance-Stock Volume, High Pressure, Shark Tooth, 3/4"	ADD
10555ST	Performance-25% Increased Volume, High Pressure, Shark Tooth, 3/4"	ADD

Gaskets

Part #	Application
1882	Stroker Oil Pan Gasket (1957-1985)	ADD
OS34510T	Left or Right Hand Dipstick – 2 Piece Rear Seal (1957-1985)	ADD

Miscellaneous Accessories

Part #	Description
K125	High Pressure Oil Pump Spring	ADD
DP-1	Drain Plug	ADD
DP-1M	Magnetic Drain Plug	ADD
230-7002	ARP Oil Pump Stud	ADD
IS-55E	Melling Intermediate Oil Pump Drive Shaft	ADD
